News -1
4Q,2021 Audio-HAC-Application new released
Developed to support ANSI C63.19 2019 Compatibility between WCD and Hearing Aids section 6 WD T-Coil Signal Test
Automated test routines to assess the following
-ABM 1 / ABM 2 / Frequency Response and Quality (SNR)
-Test report providing all relevant data needed by regulators including charts, heat map and calibration data
-Spectral filters: 1/3 octave, Full-band integrator, Half-band integrator
Option to define area scan modes with a minimum of 0.02 mm resolution (typical 50x50x2 mm, 50x50x5 mm for HAC tests)
Interpolation of physical scan to 1mm spatial for HAC assessments
Assess wireless ear buds and hearing aid tele-coil with 3D mapping
Measure frequency response to >20kHz
Full EMI Near-Field operating system with data exportation
User defined point, measurement analysis and reporting
1Q,2021 EM-ISight V5.1 x64 Released .
Windows 10, Office 2019 , Office 2003 shipped on systems
[FMS] Frequency Multi-Span version 1.0 (License required to activate this feature)
Add multiple instrument settings indexes in the instrument settings form. At each point in the measurement, the indexes will be executed in order, and the trace data saved to an auto-incrimented file.
Trace data from each span saved to a separate EMI2 or TXT file
Instrument data form multi-span displayed in frmMeasurement in real-time
MultiSpan preview form added with indexed peak list for each multi-span file. When the index is selected, the maxhold/avg trace applied to all points in the file is displayed. MultiSpan preview form is used to quickly browse the measured peak and maxhold/avg trace dataThe user can select a desired multi-span file to be loaded in the dataReview form.
Frequency multi-span automation for Spectrum Analyzer Instruments
Frequency multi-span automation for Network Analyzer Instruments
USB Camera disable feature will disable the USB port during the measurement that will eliminate the camera noise [administrator login only]
|
Audio-HAC-Application

FFA Cubic Volume Scan z Decay Analysis
|
| : | : |
News -2
4Q.2020 EM-ISight V5.0x64 Released .
[PCT] tool transform editing interface for probe centering, short (72mm) and long (172mm) probe support
improve accuracy of the VCS2 camera to probe alignment with software managed hand-eye calibration process
[Network Analyzer Remote] ANRITSU VNA MS464xB/ME7838 instrument added
MS4642B 10MHz to 20GHz
MS4644B 10MHz to 40GHZ
MS4647B 10MHz to 70GHz FW V2020.5.1 verified
ME7838A,ME7838E 70KHz to 110GHz
ME7838D 70KHz to 145GHz
ME7838G 70KHz to 220GHz
2D magnitude overlay marker diameter scaling
load picture cropping and editing features improved (Jr. Programmer Tony Z)
version 5.0 activation code entry required for dongles with a version 4.6 or earlier license
4Q, 2019 RC7m_KCE4.6.2929 upgrade
4Q, 2019 RC8A_KCE_4.6.2879 upgrade
4Q, 2019 EMISight_4.6.2977x64 Released
Power Signature plot added that will plot the maximum power out of all frequencies for each point
Theta SUM feature that will RMS sum the power for each probe theta position into one point
Flux and Current vector overlay mode onto DUT image
Frequency marker feature added to spectrum plot. Maximum of 4 markers.
[Trace1] - [Trace2] delta feature added to EMI-debug tool bar
4D plot video generation
improved touch detection and DUT teaching performance
improved word report generation performance
Watermark feature added to word report generation.
ESD Current tracing module that supports Time and Frequency domain acquisition and data overlays
Zoom in DUT teaching and SPLayer form
move to blue peak function in SPLayer form to validate probe position in measurements before scan starts
real time DUT location update when teaching DUT
vision capture system version 1 support
3Q, 2019 EMISight_4.6.2925x32 last upgrade(Features added from 4.4 to 4.5)
2Q,2018 , EM-ISight v4.5.2805_upgrade Released (bug fixes in V4.5.2283)
|
probe centering tool
[ESD-Current Tracing] Upgrade system
EM-ISight Vision System
|
| : | : |
News -3
2Q, 2017 EM-ISight V4.5.2283 Released.
Features added from 4.4 to 4.5
Power Signature plot added that will plot the maximum power out of all frequencies for each point
Theta SUM feature that will RMS sum the power for each probe theta position into one point
Flux and Current vector overlay mode onto DUT image
Frequency marker feature added to spectrum plot. Maximum of 4 markers.
[Trace1] - [Trace2] delta feature added to EMI-debug tool bar
4D plot video generation
improved touch detection and DUT teaching performance Power Signature Plot with Theta SUM feature, and current vector overlay
improved word report generation performance
Watermark feature added to word report generation.watermark text can be input in the EMISight Configuration form.The watermark field is under the word report title field.The watermark text will be overlayed on each page of the word report.
ESD Current tracing module that supports Time and Frequency domain acquisition and data overlays Time domain data acquisition is phase synchronized using dual channel acquisition stationary Air Trigger probe for trigger, APREL HxyESD fortified probe on robot for data acquisition Minimum requirements 20 GSa/s Osciloscope and 4GHz bandwidth (Keysight or Tektronix)
Zoom in DUT teaching and SPLayer form
move to blue peak function in SPLayer form to validate probe position in measurements before scan starts
real time DUT location update when teaching DUT
vision capture system version 1 support
4Q,2016 APREL [ESD-Current Tracing] Upgrade system released
[ESD-CM] ESD Current Mapping.
ESD Current Mapping measurement in time and frequency simultanilously.
ESD Current Mapping in time domain.
ESD Current Mapping in frequency domain
Oscilloscope automation for Tektronix DPO, Keysight DSO.
2Q,2015 , EM-ISight V4.3.1757 Released.
EMIS-SR Standard reach configuration features a work area with 432 mm radius
EMIS-ER Extended reach configuration features a work area with 810 mm radius
EMIS-LR Long reach configuration features a work area with 1200 mm radius
|
Power Signature Plot with Theta SUM feature
Vertical Scanning Planes for 6 Axis Robot
ESD-Current Tracing] Upgrade system


|
|
|
|
|
